The Resultant Vector

Free Preview of The Ultimate Crash Course for STEM Majors

This lesson is nothing more than a free preview of The Ultimate Crash Course for STEM Majors.

Visit AuthorJonD.com to explore the Crash Course series, books, lessons, and additional educational material.

You can also check out my fiction, books, stories, and other creative work at AuthorJonD.com.

All vectors repositioned tail at origin, and angle from 0°.

Then you can simply take the angle from the origin with cosine and sine and sum them.

$$ \vec{R}=\left\langle \sum x,\sum y\right\rangle $$

$$ |\vec{R}|=\sqrt{\left[\sum x\right]^2+\left[\sum y\right]^2} $$

$$ \theta=\arctan\left[\frac{\sum y}{\sum x}\right] $$

NOTE* Depending on which quadrant you are in, you may have to add 90 or 180 degrees.

Then, the Resultant vector will be,

$$ \vec{A} = \langle |\vec{A}|\cos\alpha,|\vec{A}|\sin\alpha\rangle, \qquad \vec{B} = \langle |\vec{B}|\cos\beta,|\vec{B}|\sin\beta\rangle, \qquad \vec{C} = \langle |\vec{C}|\cos\gamma,|\vec{C}|\sin\gamma\rangle. $$

$$ R_x = |\vec{A}|\cos\alpha + |\vec{B}|\cos\beta + |\vec{C}|\cos\gamma = A_x+B_x+C_x, $$

$$ R_y = |\vec{A}|\sin\alpha + |\vec{B}|\sin\beta + |\vec{C}|\sin\gamma = A_y+B_y+C_y, $$

$$ \vec{R} = \langle R_x,R_y\rangle = \langle A_x+B_x+C_x,A_y+B_y+C_y\rangle, $$

$$ |\vec{R}| = \sqrt{ [A_x+B_x+C_x]^2 + [A_y+B_y+C_y]^2 }, $$

$$ \tau = \arctan \left[ \frac{A_y+B_y+C_y} {A_x+B_x+C_x} \right]. $$

The resultant vector that we found is the same as finding the net force or work … as you progress deeper into the course.

• The first 4 or 5 chapters of the book lead up to learning how to work with all the vectors. Then, it basically repeats itself just calling the resultant something like net force or total work, …
